Madler 62345000GR Coupling Element

Madler 62345000GR Coupling Element

Madler 62345000GR Coupling Element

Product Description :

• It is used in mechanical systems to connect two shafts or components, enabling them to transmit rotational motion or torque.They play a crucial role in aligning shafts, compensating for misalignment, and reducing the transmission of vibrations and shocks.
• It accommodate slight angular, parallel, or axial misalignments between connected shafts.Absorbs and reduce vibrations and shocks transmitted between shafts, enhancing system reliability and reducing noise.
• It protect machinery from damage due to misalignment, shocks, and overloads.

Product Specification :

• Material	Steel (1045)
  Surface	Black oxide finish
  Bore diameter [d1]	50 [mm]
  Outer diameter [d2]	82 [mm]
  Max. outer diameter over screw head [Rmax.]	84.2 [mm]
  Width [b]	19 [mm]
  Screw DIN 912 (Thread size x length) [Schrauben]	M 8 x 25
  mounting hole center distance [m]	29 [mm]
  Thread size [G]	M 6 [mm]
  Thread length [t]	8.5 [mm]
